2.5G Ethernet Switches

Low power switch is world's 1st with eight integrated 2.5G PHYs

Press Release Learn More

The demand for more robust Ethernet products is growing as 2.5G speeds expand into enterprise, retail, and industrial single and multiport applications, and more PCs offer 2.5G Ethernet ports.

The new MxL8628x and MxL8625x switches are optimized for 2.5G Ethernet, providing customers with a rich set of features while being substantially lower power and cost optimized relative to 10G and unoptimized 2.5G devices.


MaxLinear's 2.5G Optimized Ethernet Switch Advantages

Extensive IOP

> 100 link partners


  • Robust link-up in all rates and modes
  • Field proven architecture

Excellent Reach

up to 130m


  • +20% over IEEE 100m spec

Power Optimized

< 650mW/port


  • Much lower power than 10G architectures
  • Supports EEE for 2.5G, 1000, and 100



Cost Optimized

Fraction of 10G and unoptomized 2.5G PHYs


  • Enables cost-effective 2.5G Ethernet multiport applications

Rich Feature Set

Variants to support different needs


  • Web-smart switch
  • Commercial and industrial temperature
  • PTP, SyncE, MACsec

Senior Director of Marketing, Interface Products Raman Sargis talks about the benefits of MaxLinear's 2.5G Ethernet solution.

a video thMaxLinear 2.5G Ethernet Solutions
1:11
#wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset{font-size:14px;} #wistia_chrome_123 #wistia_grid_129_wrapper div.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper span.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper ul.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper li.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper label.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper fieldset.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper button.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper img.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper a.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper svg.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper p.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper a.w-css-reset{border:0;} #wistia_chrome_123 #wistia_grid_129_wrapper h1.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:2em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper h2.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:1.5em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper h3.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:1.17em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper p.w-css-reset{margin:1.4em 0;} #wistia_chrome_123 #wistia_grid_129_wrapper a.w-css-reset{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper span.w-css-reset{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper svg.w-css-reset{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper ul.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper ol.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper li.w-css-reset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper ul:before.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper ol:before.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper li:before.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper ul:after.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper ol:after.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper li:after.w-css-reset{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper label.w-css-reset{background-attachment:scroll;background-color:transparent;background-image:none;background-position:0 0;background-repeat:no-repeat;background-size:100% 100%;float:none;outline:none} #wistia_chrome_123 #wistia_grid_129_wrapper button.w-css-reset{background-attachment:scroll;background-color:transparent;background-image:none;background-position:0 0;background-repeat:no-repeat;background-size:100% 100%;border:0;border-radius:0;outline:none;position:static} #wistia_chrome_123 #wistia_grid_129_wrapper img.w-css-reset{border:0;display:inline-block;vertical-align:top;border-radius:0;outline:none;position:static} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset button::-moz-focus-inner{border: 0;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree {font-size:14px;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree div{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree span{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ul{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree li{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree label{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree fieldset{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree button{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree img{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree a{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree svg{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree p{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree a{border:0;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree h1{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:2em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree h2{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:1.5em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree h3{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:1.17em;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree p{margin:1.4em 0;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree a{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree span{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree svg{display:inline;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ul{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ol{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree li{box-sizing:inherit;box-shadow:none;color:inherit;display:block;float:none;font:inherit;font-family:inherit;font-style:normal;font-weight:normal;font-size:inherit;letter-spacing:0;line-height:inherit;margin:0;max-height:none;max-width:none;min-height:0;min-width:0;padding:0;position:static;text-decoration:none;text-transform:none;text-shadow:none;transition:none;word-wrap:normal;-webkit-tap-highlight-color:rgba(0,0,0,0);-webkit-user-select:none;-webkit-font-smoothing:antialiased;list-style-type:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ul:before{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ol:before{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree li:before{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ul:after{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree ol:after{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree li:after{display:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree label{background-attachment:scroll;background-color:transparent;background-image:none;background-position:0 0;background-repeat:no-repeat;background-size:100% 100%;float:none;outline:none} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree button{background-attachment:scroll;background-color:transparent;background-image:none;background-position:0 0;background-repeat:no-repeat;background-size:100% 100%;border:0;border-radius:0;outline:none;position:static} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree img{border:0;display:inline-block;vertical-align:top;border-radius:0;outline:none;position:static} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-tree button::-moz-focus-inner{border: 0;} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-max-width-none-important{max-width:none!important} #wistia_chrome_123 #wistia_grid_129_wrapper .w-css-reset-button-important{border-radius:0!important;color:#fff!important;}
#wistia_grid_129_wrapper{-moz-box-sizing:content-box;-webkit-box-sizing:content-box;box-sizing:content-box;font-family:Arial,sans-serif;font-size:14px;height:100%;position:relative;text-align:left;width:100%;} #wistia_grid_129_wrapper *{-moz-box-sizing:content-box;-webkit-box-sizing:content-box;box-sizing:content-box;} #wistia_grid_129_above{position:relative;} #wistia_grid_129_main{display:block;height:100%;position:relative;} #wistia_grid_129_behind{height:100%;left:0;position:absolute;top:0;width:100%;} #wistia_grid_129_center{height:100%;overflow:hidden;position:relative;width:100%;} #wistia_grid_129_front{display:none;height:100%;left:0;position:absolute;top:0;width:100%;} #wistia_grid_129_top_inside{position:absolute;left:0;top:0;width:100%;} #wistia_grid_129_top{width:100%;position:absolute;bottom:0;left:0;} #wistia_grid_129_bottom_inside{position:absolute;left:0;bottom:0;width:100%;} #wistia_grid_129_bottom{width:100%;position:absolute;top:0;left:0;} #wistia_grid_129_left_inside{height:100%;position:absolute;left:0;top:0;} #wistia_grid_129_left{height:100%;position:absolute;right:0;top:0;} #wistia_grid_129_right_inside{height:100%;right:0;position:absolute;top:0;} #wistia_grid_129_right{height:100%;left:0;position:absolute;top:0;} #wistia_grid_129_below{position:relative;}
Products

MxL86282 Ethernet Switch sets a New Standard in 2.5G Ethernet


MxL86282 family offers rich set of features while being substantially lower power and cost optimized relative to 10G and unoptimized 2.5G PHYs


  • Eight 2.5G Ethernet PHYs
  • Two 10G SerDES Interfaces
  • 80Gbps Unblocked Switching
  • Low Power Consumption
  • Feature-rich Web-smart Switch (VLAN, QoS, Loop Detection, ACL)


Read the Press Release

Download the Flyer

Click me
MxL8628x
2.5G Ethernet Switches w/8 PHYs
  • Low power consumption through high integration
  • Power saving modes for short cable, through Energy Efficient Ethernet (EEE) and no-link detection
  • Integrated processor enables web-smart switch applications

  • Three commercial temp options:
    • MxL86280C: 8-port
    • MxL86282C: 10-port
    • MxL86282S: 10-port, web-smart support
  • One industrial temp option:
    • MxL86282I: 10-port, web-smart support
  • Supports XFI and USXGMII interfaces
  • Wire speed switching between all ports
  • Features include: VLAN, QoS, loop detection, ACL
  • Eight integrated 2.5GBASE-T PHYs
    • 2.5GBASE-T, 1000BASE-T, 100BASE-TX and 10BASE-Te link rates
  • 12mm x 12mm package
Learn More
MxL8625x
2.5G Ethernet Switches w/5 PHYs
  • Low power consumption through high integration
  • Power saving modes for short cable, through Energy Efficient Ethernet (EEE) and no-link detection
  • Integrated processor enables web-smart switch applications

  • Three commercial temp options:
    • MxL86250C: 5-port
    • MxL86252C: 7-port
    • MxL86252S: 7-port, web-smart support
  • One industrial temp option:
    • MxL86252I: 7-port, web-smart support
  • Supports XFI, USXGMII, and SGMII interfaces
  • Wire speed switching between all ports
  • Features include: VLAN, QoS, loop detection, ACL
  • Five integrated 2.5GBASE-T PHYs
    • 2.5GBASE-T, 1000BASE-T, 100BASE-TX and 10BASE-Te link rates
  • 12mm x 12mm package
Learn More
MxL86289
Octal Port 2.5G Ethernet PHY
  • Octal port enterprise grade Ethernet PHY
  • 2.5GBASE-T, 1000BASE-T, 100BASE-TX and 10BASE-Te link rates
  • Two USXGMII-M MAC interfaces
  • 13mm x 13mm package
  • Commercial and industrial temperature versions

  • Low power consumption through high integration and dedicated 2.5G design







Learn More
Resources

Videos

Senior Director of Marketing, Interface Products Raman Sargis talks about the benefits of MaxLinear's 2.5G Ethernet solution.


Documentation


Flyers, Brochures & White Papers

Brochures

Ethernet Brochure

Product Flyers

MxL86280_MxL86282
MxL86250_MxL86252
GSW1xx

White Papers

Enabling Multi-Gig Connectivity with High-Performance 2.5G Ethernet

Technical Documentation & Application Notes

Register for a myMxL account and contact your local MaxLinear sales person to request access or Login to myMxL to view all Technical Documentaiton & Design Tools.
